Fire Truck Accessories Security Proofing Rolling Shutter Door, FX roll up door for fire truck, roller shutter door, rolling shutters, rolling door, aluminum garage door, steel security door, metal door, sliding door, automatic door, the most competitive products with high quality of our company.
Why choose FX Roll Up Doors?
Strong, lightweight anodized aluminum for an attractive appearance
Quick and easy installation
Fast and easy opening and closing
Provide full view of compartment
Easy access to equipment
Keeps personnel safe by allowing them to remain closer to the vehicle
Eliminates damage associated with swing-out doors
Available in custom painted finishes
Manufactured in China
Name:
Roll Up Doors for fire trucks, Rolling Door, Aluminum Garage Door, Steel Security Door
Fire Trucks Aluminium Automatic Rolling Shutter
Design Highlights and Specifications:
The charts below give approximate dimensions for roll up door diameters, compartment depths required, and maximum internal heights allowed for given door widths.
Recommended Header Height (inches) 2.5" is minimum required
Internal Height Minimum Depth Header Height Roll p Diameter
Up to 25 10.000 2.500 5.375
26 to 35 10.500 2.500 6.000
36 to 50 11.500 3.250 7.250
51 to 60 11.875 3.875 7.750
61 to 70 12.375 4.250 8.250
71 to 90 13.500 5.375 9.375
91 to 104 14.125 6.500 10.50
Roll Up Door Opening vs Maximum Internal Height (inches)
Door Opening Width Maximum Internal Height
18.000 30.000
19.000 40.000
20.000 56.000
21.000 60.000
22.000 to 27.000 90.000
28.000 to 32.000 100.000
33.000 to 78.000 110.000
Standard Features of Truck Body Fittings Roll Up Doors for fire trucks
Spring loaded operator for ease of lifting roll up door.
| Item |
Unit |
Parameter |
| Product name |
Fire truck roller shutter, fire fighting truck roll up door |
| Water tank volume |
L |
2000 |
| Overall dimensions |
mm |
6260×1900×2750 |
| Gross weight |
kg |
6495 |
| Curb weight |
3065,3000 |
| Payload capacity |
3250,3315 |
| Axle load |
2620/3875 |
| Wheelbase |
mm |
3300 |
| Front/Rear track base |
1506/1466 |
| Front/Rear overhang |
1032/1488 |
| Approach/Departure angle |
° |
17/13 |
| Exhaust/Power |
ml/hp |
3856/95 |
| Max speed |
km/h |
90 |
| Emission standard |
Euro III |
| Engine model |
CY4102-C3F |
Electric system |
24V |
| Traction system |
4×2 |
Number of axles |
2 |
| Tire specifications |
7.00-16 |
Number of tires |
6 |
| Operation control system |
Electrically hydraulic control |
Allowable passengers in cab |
2+3,3+3 |
| Equipments and Performance |
1. Water pump: CB10/20.
2. Fire cannon: PS20
3. PTO (Power Take Off)
4. 5-7 curtain doors equipment boxes
5. 1100mm long row lights |
| Production cycle |
7-10 days |
| warranty |
12 month, from the date of supply |
Competitive Advantages
Well and High Quality Control ,
Prompt Delivery ,
New Product ,
Competitive Prices ,
Earth-friendly Products ,
Small Order Acceptable.
